Sayam Nickel Alloys is a reputable manufacturer and supplier located in Hyderabad, India, specializing in high-quality Titanium Tube Fittings for essential industrial applications. Crafted from top-grade titanium and utilizing cutting-edge machining technology, these fittings are built to comply with international quality standards. Sayam Nickel Alloys guarantees exceptional dimensional accuracy, leak-proof performance, and a long lifespan. Their titanium tube fittings find extensive use in sectors like chemical processing, oil & gas, marine, aerospace, power generation, and pharmaceuticals, where corrosion resistance, reliability, and safety are paramount.
The Titanium Tube Fittings are made from commercially pure titanium or titanium alloys, such as Grade 5, tailored to meet specific service needs. This material boasts an impressive strength-to-weight ratio, high tensile strength, and good ductility. On a mechanical level, titanium fittings provide remarkable fatigue resistance and stability, even under varying pressure and temperature conditions. They also demonstrate outstanding resistance to corrosion from seawater, chlorides, acids, and harsh industrial chemicals, ensuring reliable performance in demanding environments.
| Specifications (ASTM/ASME) | ASTM B381/381M R56400, ASME SB381/381M R56400 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Types we Offer | Titanium Instrumentation Fittings Ti Grade 5 Double Ferrule Fittings Ti Grade 2 Twin Ferrule Fittings Ti-6al-4v Eli Titanium Ferrule Fittings Pure Titanium Pneumatic Fittings Ti Grade 6 Flare Fittings Cp Gr2 Ti JIC Fittings Tial6v4 Instrumentation Fittings Ti Alloy Grade 5 Hydraulic Hose Fittings ASTM B348 Grade 5 Compression Fittings Cp Grade 1 Double Ferrule Fittings ASME SB 348 Grade 2 Push-To-Connect Fittings Grade 5 Compression Fittings Ti Gr2 Hydraulic Fittings |
| Material Grades | Titanium Gr.5 – UNS R56400, Titanium Gr 2 – UNS R50400 |
| THREAD | BSPT, UNF, BSP, NPT, ISO, SAE, etc. |
| Forms | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Working Pressure | Upto 2000 to 6000 PSI |
| Medium – Pressure Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) |
| Body Type | FORGED, BAR STOCK |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Surface | Export bright finish, short blasted finish, electroplated finish |
| Applications Temperature | 150-400°C |
| Ends | Welding, Threaded, JIC |
| Packing Details | As per your detailed request Normally carton size – 21*16*14CM/31*21*16CM/36*45*50CM Normally wooden box size – 38*27*17CM Normally 1piece/ opp, 10-20pcs/ carton |
| Element | Ti | C | Fe | H | N | O | Al | V |
| Titanium | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tube Fittings in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Tube Fittings play a vital role in fluid and gas handling systems, especially where corrosion resistance and strength are essential. You’ll often find them in chemical processing plants, offshore oil and gas platforms, and marine systems. In industries like aerospace and power generation, these fittings are crucial for managing high-pressure and high-temperature lines. They’re also key players in pharmaceutical manufacturing, desalination plants, heat exchangers, and precision instrumentation systems that demand leak-proof and durable connections.
