Sayam Nickel Alloys, located in Hyderabad, stands out as a top manufacturer and supplier of high-performance Super Duplex Manifold Valves. These valves are celebrated for their remarkable corrosion resistance, strength, and durability, designed to meet the toughest industrial standards. With a commitment to quality and precision, Sayam Nickel Alloys rigorously tests and crafts each valve to ensure long-lasting reliability in challenging environments. Catering to sectors like oil and gas, chemical processing, and marine applications, the company merges advanced metallurgy with expert engineering to deliver solutions that boost operational efficiency and safety across various industries.
Super Duplex Manifold Valves are crafted from super duplex stainless steel, typically containing 22–25% chromium, 4–6% molybdenum, 5–7% nickel, along with trace amounts of nitrogen, manganese, and copper. This unique alloy composition strikes the perfect balance between corrosion resistance and mechanical strength. In terms of mechanics, these valves showcase impressive tensile strength (around 850–1000 MPa), excellent yield strength (approximately 550–700 MPa), and remarkable toughness even in low temperatures. They also boast exceptional resistance to stress corrosion cracking, pitting, and crevice corrosion, making them ideal for highly corrosive and high-pressure industrial settings.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Manifold Valve in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Sayam Nickel Alloys’ Super Duplex Manifold Valves find extensive use in industries where durability, reliability, and corrosion resistance are paramount. They are perfect for oil and gas pipelines, offshore platforms, chemical processing facilities, desalination plants, and marine applications. These valves effectively control the flow of corrosive fluids, gases, and high-pressure liquids while keeping maintenance to a minimum. Their sturdy construction guarantees consistent performance even under extreme conditions, ensuring that they meet the rigorous demands of various industrial environments.
