Sayam Nickel Alloys, located in Hyderabad, stands out as a top manufacturer and supplier of high-quality Super Duplex Ball Valves. These valves are specifically designed to thrive in tough industrial settings, offering remarkable corrosion resistance, durability, and precision engineering. Each valve is meticulously crafted using cutting-edge metallurgy to guarantee outstanding performance even under high pressure, extreme temperatures, and harsh chemical environments. Trusted by industries like oil and gas, chemical processing, offshore, and marine, Sayam Nickel Alloys provides dependable solutions that prioritize operational safety and efficiency. Their unwavering commitment to quality and rigorous testing makes their Super Duplex Ball Valves the go-to choice for critical applications.
Super Duplex Ball Valves are made from super duplex stainless steel, which typically includes 22–25% chromium, 5–7% nickel, and 3–5% molybdenum, along with small amounts of nitrogen and copper. This unique blend offers an ideal mix of mechanical strength and corrosion resistance. In terms of mechanics, these valves showcase impressive tensile strength (around 850–1000 MPa), notable yield strength (approximately 550–700 MPa), and excellent toughness, even in low temperatures. They are resistant to pitting, crevice corrosion, and stress corrosion cracking, making them perfect for demanding industrial environments. Their sturdy design ensures long-lasting reliability in high-pressure and corrosive situations.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Ball Valve in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Sayam Nickel Alloys’ Super Duplex Ball Valves find extensive use in industries that require dependable flow control in extreme conditions. They are commonly utilized in oil and gas pipelines, offshore platforms, chemical processing facilities, water desalination plants, and marine systems. These valves effectively manage the flow of corrosive liquids and gases, ensuring precise shut-off and control.
