Home > Rene 41 Sheets and Plates
Sayam Nickel Alloys, located in Hyderabad, is a reputable manufacturer and supplier of high-performance Rene 41 Sheets and Plates. Renowned for their remarkable strength, thermal stability, and resistance to oxidation, these products are crafted for extreme high-temperature environments. Utilizing cutting-edge nickel-based superalloy technology, Sayam Nickel Alloys guarantees consistent quality, precision, and reliability in every sheet and plate. Catering to industries like aerospace, power generation, and high-temperature processing, Rene 41 Sheets and Plates excel under severe thermal and mechanical stress, making them the go-to choice for critical and demanding engineering applications.
Rene 41 Sheets and Plates are made from a nickel-based superalloy that includes about 19–21% chromium, 10–11% cobalt, 3–4% molybdenum, 3–4% titanium, and 1.5–2% aluminum, along with trace amounts of carbon and boron. This unique blend offers outstanding high-temperature strength and oxidation resistance. On the mechanical side, Rene 41 boasts high tensile and yield strength, exceptional creep resistance, and solid fatigue properties. These sheets and plates maintain their structural integrity and toughness even at temperatures above 700°C, making them perfect for extreme thermal and stress-heavy environments.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Rene 41 Sheets and Plates from Sayam Nickel Alloys find extensive use in aerospace, gas turbine engines, rocket motor components, and high-temperature industrial equipment. They are particularly suited for crafting combustion chambers, exhaust systems, heat shields, and structural components that face extreme heat and stress. Additionally, these products are utilized in power generation and defense sectors where thermal stability and mechanical strength are paramount. Their exceptional resistance to high temperatures and mechanical stress makes them a reliable choice for demanding applications.
