Sayam Nickel Alloys stands out as a leading manufacturer and supplier of Inconel Forged Fittings in Hyderabad, delivering top-notch solutions for challenging industrial needs. Known for their precision engineering and rigorous quality control, the company is committed to meeting international standards, ensuring that each product offers reliability, durability, and resistance to corrosion. With cutting-edge manufacturing facilities and a skilled technical team, Sayam Nickel Alloys crafts forged fittings that excel in extreme conditions. Their Inconel Forged Fittings are highly sought after in sectors that demand strength, heat resistance, and long-lasting performance, making them perfect for applications in chemical, aerospace, marine, and power generation industries.
Inconel Forged Fittings are crafted from nickel-chromium-based superalloys, typically incorporating iron, molybdenum, and trace amounts of other alloying elements to boost mechanical strength and corrosion resistance. This unique composition offers remarkable resistance to oxidation, scaling, and harsh environments at elevated temperatures. On the mechanical side, Inconel Forged Fittings showcase impressive tensile and yield strength, outstanding creep and fatigue resistance, and solid toughness across a broad temperature spectrum. They maintain their shape and stability even under extreme heat and stress, ensuring dependable performance in critical piping and industrial systems.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Forged Fittings in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Inconel Forged Fittings find extensive use in industries that demand components with high strength, corrosion resistance, and heat tolerance. They are commonly utilized in chemical and petrochemical plants, gas turbines, power generation equipment, marine engineering, and aerospace systems. These fittings are particularly suited for high-pressure and high-temperature piping systems, heat exchangers, and valves, where durability and reliability are paramount.
