Sayam Nickel Alloys is a reputed manufacturer and supplier of high-quality Incoloy 825 forged fittings in Hyderabad, India. Our forged fittings are produced using advanced forging techniques and premium-grade raw materials to ensure superior strength, dimensional accuracy, and long service life. Designed to withstand severe corrosion, high pressure, and elevated temperatures, our Incoloy 825 forged fittings meet international standards and industry specifications. Widely supplied to chemical processing, oil and gas, petrochemical, marine, and power generation industries, Sayam Nickel Alloys is committed to quality assurance, timely delivery, and customized solutions.
Incoloy 825 Forged Fittings offer outstanding advantages, including excellent resistance to corrosion, especially in acidic and oxidizing environments. They maintain structural integrity under high temperatures and pressures, making them ideal for demanding applications. These fittings are highly resistant to pitting, crevice corrosion, and stress corrosion cracking. Their robust mechanical properties ensure durability and longevity, reducing maintenance needs. Incoloy 825 Forged Fittings are perfect for use in chemical processing, oil and gas, and marine environments, where reliability is paramount.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
Incoloy 825 is a nickel-iron-chromium alloy containing molybdenum, copper, and titanium, offering excellent resistance to corrosion and oxidation. High nickel content protects against stress corrosion cracking, while chromium enhances oxidation resistance. Molybdenum improves resistance to pitting and crevice corrosion, and copper provides superior performance in acidic environments. Titanium stabilizes the alloy against intergranular corrosion. Incoloy 825 forged fittings exhibit good tensile and yield strength, excellent ductility, and toughness, ensuring mechanical stability under high-pressure and high-temperature conditions.
Contact us to get a quick quote for your requirement.
Incoloy 825 forged fittings are extensively used in industries requiring reliable performance in aggressive environments. Typical applications include chemical processing plants, acid handling systems, oil and gas pipelines, offshore platforms, and marine equipment. These fittings are also used in heat exchangers, pressure vessels, pollution control systems, and power generation units. Their excellent resistance to sulfuric and phosphoric acids, combined with high mechanical strength, makes Incoloy 825 forged fittings ideal for high-pressure fluid systems and critical piping connections where durability, safety, and long service life are essential.
